A CS-RING is an open, round-wire shaft retaining component installed in an external groove around a shaft. Once seated in the groove, it helps limit the axial movement of bearings, gears, pulleys, bushings, and other components. Its circular cross-section fits closely against the groove base, making it suitable for shaft-end retaining structures with limited installation space.

Product Name: CS-RING / CS-Type Retaining Ring / Circular Retaining Ring
Product Type: Round-Wire Shaft Retaining Ring
Product Structure: Open circular ring formed from round wire
Primary Functions: Axial positioning, stopping, and preventing components from becoming detached
Installation Position: Annular groove on the outside of a shaft
Applicable Shaft Diameter: Selected according to shaft diameter and groove dimensions
Wire Diameter: Determined according to shaft diameter, load, and available installation space
Groove Dimensions: Groove diameter, groove width, and groove depth manufactured according to applicable specifications
Materials: Spring steel, carbon steel, stainless steel, or other specified materials
Heat Treatment: Applied according to hardness, elasticity, and fatigue-resistance requirements
Surface Treatments: Phosphate coating, black oxide, zinc plating, nickel plating, or passivation
Available Specifications: Metric, imperial, or custom-made according to drawings
Production Methods: Wire forming, heat treatment, and surface treatment

Category:

Round-Wire Structure Fits the Groove

The circular cross-section fits into the shaft groove and seats against the groove base, forming an axial stop that helps restrict the axial movement of mating components.

Compact Installation Space

The compact ring structure can reduce the need for nuts, end caps, and multiple washers, making the CS-RING suitable for small assemblies or mechanisms with limited shaft-end space.

Elastic Tension Maintains Retention

The CS-RING elastically deforms during installation. Once seated in the groove, it recovers toward its original shape and maintains spring tension, helping reduce the possibility of accidental disengagement.

Available in Metric and Imperial Sizes

Metric or imperial specifications can be selected according to the shaft diameter and groove dimensions, making the CS-RING compatible with different machinery and component systems.

Suitable for Various Shaft Assemblies

CS-RINGS are commonly used in motors, gears, bearings, pulleys, automotive and motorcycle components, electronic equipment, and automation mechanisms.
