Heat Sink Screw

A Heat Sink Screw is a functional fastener that combines a screw with a spring structure. It is primarily used for securing CPU heat sinks, thermal modules, and motherboards. The spring provides continuous and appropriate pressure to maintain stable contact between the heat sink and CPU while compensating for assembly tolerances and vibration, helping improve the overall stability of the thermal module.

Product Name: Heat Sink Screw / CPU Heatsink Spring Screw
Product Structure: Combination of screw, compression spring, and positioning structure
Primary Applications: CPU heat sinks, thermal modules, and motherboard mounting
Head Types: Phillips, hex socket, Torx, or other specified head types
Thread Specifications: Metric, imperial, or customized according to heat sink module requirements
Primary Dimensions: Thread diameter, thread pitch, screw length, and spring dimensions
Spring Specifications: Wire diameter, outside diameter, free length, and load can be designed according to application requirements
Screw Materials: Carbon steel, stainless steel, or other specified materials
Spring Materials: Spring steel, stainless steel, or other specified materials
Surface Treatments: Zinc plating, nickel plating, black oxide, or other specified finishes
Production Options: Standard specifications or custom production based on drawings
Taiwan Patent No.: Utility Model No. 216161
China Patent No.: ZL 01 267418.4

Maintains Stable Contact Between the CPU and Heat Sink

The spring continuously provides axial pressure to help maintain proper contact between the heat sink and CPU surface, supporting stable operation of the thermal module.

Balances Fastening Pressure

The spring can compensate for variations in height and assembly tolerances, reducing excessive concentration of fastening force at a single mounting point and helping distribute pressure more evenly across the heat sink.

Helps Reduce the Risk of Component Damage

The elastic spring structure helps cushion fastening force and reduces the possibility of deformation caused by over-tightening around the motherboard, CPU area, or heat sink module.

Suitable for High-Volume Heat Sink Module Assembly

By integrating the screw and spring into a single fastening component, the Heat Sink Screw can simplify material preparation and installation procedures, making it suitable for thermal modules used in computers, servers, and other electronic equipment.

Patented Product Design by Cashi Components CO., LTD.

This product is a patented product of Cashi Components CO., LTD., protected by Taiwan Utility Model Patent No. 216161 and China Patent No. ZL 01 267418.4. Different dimensions and specifications can be provided according to CPU heat sink module requirements.
