LEAD SCREW
LEAD SCREW Structure

LEAD SCREW

A LEAD SCREW is a power-transmission component that converts rotary motion into linear movement. It is typically used together with a nut, bearings, and a drive mechanism. Through the thread lead, it moves a platform or mechanism along a linear path, making it suitable for positioning, lifting, pushing, and travel adjustment applications.

Product Name: LEAD SCREW / Power Screw
Thread Types: Trapezoidal thread, square thread, ACME thread, or other specified thread profiles
Thread Direction: Right-hand, left-hand, or bidirectional thread
Thread Starts: Single-start, multi-start, or designed according to lead requirements
Primary Dimensions: Outside diameter, thread pitch, lead, effective thread length, and overall length
End Machining: Threaded ends, stepped shafts, keyways, flats, center holes, or other specified features
Accuracy Grade: Determined according to positioning accuracy and travel requirements
Materials: Carbon steel, stainless steel, alloy steel, or other specified materials
Heat Treatment: Quench-and-temper treatment, induction hardening, nitriding, or other specified treatments
Surface Treatments: Black oxide, nickel plating, chrome plating, phosphate coating, or other specified finishes
Processing Methods: Thread rolling, turning, grinding, and precision end machining
Compatible Nuts: Bronze nuts, plastic nuts, steel nuts, or anti-backlash nuts
Inspection Items: Dimensions, lead accuracy, straightness, concentricity, and thread accuracy

Category:

Converts Rotary Motion into Linear Movement

When used with a matching nut, a LEAD SCREW converts the rotational motion of a motor or handwheel into stable linear movement.

Adjustable Lead and Travel Speed

Different movement speeds and linear advances can be achieved by adjusting thread pitch, lead, and the number of thread starts, allowing the design to match different equipment travel requirements.

Provides Load-Bearing and Positioning Functions

A LEAD SCREW is suitable for carrying axial loads and can be used in mechanisms for platform positioning, lifting, clamping, pushing, and linear adjustment.

Supports Custom End Machining

Stepped shaft sections, keyways, threaded ends, flats, and other end features can be customized according to bearing, coupling, and drive-system requirements.

Suitable for Various Mechanical Equipment

LEAD SCREWS are commonly used in automation equipment, lifting platforms, valves, jigs and fixtures, 3D printers, conveying systems, and various linear-motion mechanisms.
